LDTSH-125TV-A Customize OEM Precision Shaft Design Manual Rotary Positioning Stage Platform Dimension 125mm Load Capacity 3kg

No.LDTSH-125TV-A

Product Features:
Manual rotary table series products are mainly used to adjust the rotation of objects around the central axis. The ultra-dense shaft system design and ultra-thin design can effectively reduce the overall height of the product when used in combination.

$157.00

Get The Latest Quote

Description
Services & Guarantee

TECHNICAL SPECIFICATIONS:

Model	LDTSH-125TV-A
Platform Size	Φ125mm
Coarse Adjustment	360°
Driving Mode	Micrometer screw
Fine Adjustment	±5°
Mini Scaling	10'
Micrometer Screw Per Frame	0.46'
Parallelism of Motion	40μm
Concentricity of Motion	30μm
Net Weight	0.9kg
Load Capacity	3kg

APPLICATIONS:
Scientific research, laser application, fully automatic measurement and testing, industrial automation, etc.
